Delphi FG0916 fuel pump module for the 1998-2002 Saturn SC1 and other vehicles delivers fuel from the tank to the engine. It is built to Delphi's OE standards.
- Empty float height and float retention set for a correct gas gauge reading
- Lower amperage draw, so the module puts less load on the vehicle's electrical system
- Validated, tested and matched to the right vehicle application
- Lower failure rates from the module's design and durability
Quick facts
- Part: Delphi FG0916 fuel pump module
- Also called: fuel pump assembly
- Fits: 1998-2002 Saturn SC1 and other vehicles
- Condition: New
Also called a fuel pump assembly, it is a candidate when the engine cranks but starts hard, stalls, or the gas gauge reads wrong. Those signs can mean the module is worn, though a clogged fuel filter or a faulty fuel pump relay can be behind them as well.
Fits
This Delphi fuel pump module assembly is a direct-fit replacement for the 1998-2002 Saturn SC1, the 1998-2002 Saturn SC2 and the 1998-2002 Saturn SL, and each takes one. If your Saturn is not named here, look it up by year and model in the "Vehicles it fits" section.
Specifications
- Quantity per vehicle: 1
- Condition: New
- Float arm: included
In the box
One fuel pump module with float arm, a seal and an instruction sheet.
Installation notes
- Check and clean the fuel tank before installing the module.
- The instruction sheet that comes with the part covers the steps.
Interchange: 21015152 · 4010178 · E3545 · E3951M · DFG0916 · 67356 · 67487 · 69251 · P74838M · P76540 · AFS0436S · RE0436S · D0352M · P447M · A30085 · E16082 · SP1238 · SP3951M · USEP3951M
This part cross-references / interchanges with the following part numbers:
21015152, 4010178, E3545, E3951M, DFG0916, 67356, 67487, 69251, P74838M, P76540, AFS0436S, RE0436S, D0352M, P447M, A30085, E16082, SP1238, SP3951M, USEP3951M
Frequently Asked Questions
Is this Delphi fuel pump module right for the 1998-2002 Saturn SC2?
Yes. Delphi FG0916 fits the 1998-2002 Saturn SC2, and that car takes one module.
What comes with the Delphi fuel module?
The Delphi FG0916 comes with a float arm, a seal and an instruction sheet.
Does the float on this fuel pump module read the gas gauge correctly?
Yes. Empty float height and float retention match OE specifications, which is what allows the gas gauge to read correctly.
Should I clean the fuel tank before fitting this fuel pump module?
Yes. Check and clean the fuel tank first, and follow the instruction sheet that comes with the module for the steps.
Does the Delphi FG0916 replace part number E3951M?
Yes. E3951M is one of the numbers on the Interchange line, so the Delphi FG0916 replaces it.
