Remanufactured Rear Left Brake Caliper for 2007-2017 Chevrolet Equinox & More - Raybestos FRC11921

$145.99

Vehicles this part fits

    Part number: FRC11921
    UPC: 829352627402
    Condition: Refurbished
    Weight: 7.50 LBS
    Item Package Quantity: 1
    $145.99
    Adding to cart… The item has been added

    Have questions?

    Raybestos Brakes Disc Brake Caliper P/N:FRC11921
    Raybestos Brakes Disc Brake Caliper P/N:FRC11921
    $145.99
    $145.99

    Raybestos Brakes FRC11921 rear left brake caliper for the 2007-2017 Chevrolet Equinox and other vehicles squeezes the brake pads against the rotor to slow the wheel. It is a remanufactured, semi-loaded disc brake caliper and bracket assembly.

    • Raybestos R-Line non-plated caliper remanufactured with all-new rubber and sealing components
    • Castings, guide pins and brackets are inspected before they are reused
    • Seals, boots, bleeder screws, abutment hardware, banjo bolts and O-rings replaced with new parts
    • Silicone boots for heavy-duty applications, where applicable
    • Each caliper is 100% pressure tested
    • EPDM70 rubber components for heat resistance and durability

    Quick facts

    • Part: Raybestos Brakes FRC11921 brake caliper
    • Also called: disc brake caliper
    • Fits: 2007-2017 Chevrolet Equinox and other vehicles
    • Position: Rear left
    • Material: Cast iron
    • Condition: Remanufactured

    A sticking or leaking caliper can show up as the vehicle pulling to one side, one pad wearing faster than its mate, or brake fluid near the wheel. Worn pads or a worn rotor can be behind those signs too, so find the cause before you buy.

    Fits

    The vehicles it fits include the 2007-2017 Chevrolet Equinox, the 2010-2017 GMC Terrain and the 2012-2015 Chevrolet Captiva Sport. If your vehicle isn't named here, look for it in the "Vehicles it fits" section. This listing is one caliper for the rear left; the rear right is a separate part ordered on its own, and the two sides are normally replaced together.

    Specifications

    Fit and size

    • Position: rear left
    • Quantity per vehicle: 1
    • Caliper piston diameter: 40.4 mm (1.591 in)
    • Bracket mounting hole size: 12.000 mm, thread pitch 1.750 mm
    • Bleeder screw thread: M10x1

    Build and materials

    • Caliper type: floating, semi-loaded with bracket
    • Caliper casting material: cast iron
    • Finish: non-plated
    • Condition: remanufactured
    • Country of origin: Mexico

    In the box

    One remanufactured caliper and bracket assembly.

    Interchange: 99-01420A · 18-B5040 · 18-P5040 · 141.66534 · 10-4402S · 14-4402
    SC1047

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    99-01420A, 18-B5040, 18-P5040, 141.66534, SC1047, 10-4402S, 14-4402

    Frequently Asked Questions

    Is this Chevy Equinox brake caliper right for the 2007-2017 model years?

    Yes. Raybestos Brakes FRC11921 is a rear left caliper for the 2007-2017 Chevrolet Equinox, and the 2010-2017 GMC Terrain is also covered. For another vehicle, look it up in the "Vehicles it fits" section.

    What size is the piston on this rear left caliper?

    The piston measures 40.4 mm (1.591 in) across. The bleeder screw thread is M10x1, and the bracket mounting holes are 12.000 mm with a 1.750 mm thread pitch.

    Does this remanufactured caliper get new seals and bleeder screws?

    Yes. On Raybestos Brakes FRC11921, seals, boots, bleeder screws, abutment hardware, banjo bolts and O-rings are replaced with new parts; castings, guide pins and brackets are inspected before reuse.

    How can I tell if a rear brake caliper is sticking?

    Signs can include the vehicle pulling to one side, a burning smell after driving, or one pad wearing faster than the other. A shop can test the brakes to confirm what is going on.

    Is this remanufactured caliper tested before it is sold?

    Yes. Every caliper is 100% pressure tested and also tested for reliable braking performance. Its rubber components are EPDM70.
