Front Brake Rotor for 2011-2018 Volvo S60 & More - HELLA 355118892

Be the first to review this product
$116.99
MPN: 355118892
Item Package Quantity: 1
Adding to cart… The item has been added

Have questions?

DISC BRAKE ROTOR
DISC BRAKE ROTOR
$116.99

HELLA BRAKES 355118892 front brake rotor for the 2011-2018 Volvo S60 and other vehicles gives the brake pads a vented iron surface to clamp against. This disc brake rotor is a full-cast gray cast iron disc with a coated finish.

  • High carbon content for improved heat dissipation
  • Full zinc coating for rust protection
  • High carbon content and soft casting material absorb sound and resist deformation, which reduces noise and vibration
  • Gray cast iron construction that is ECE R90 ready

Quick facts

  • Part: HELLA BRAKES 355118892 brake rotor
  • Also called: disc brake rotor
  • Fits: 2011-2018 Volvo S60 and other vehicles
  • Position: Front
  • Material: gray cast iron
  • Condition: New

A pulsing brake pedal, vibration under braking, or deep grooves and rust on the disc face can mean the rotor is worn, though worn pads or a sticking caliper can be behind them too.

Fits

The 2011-2018 Volvo S60, the 2015-2018 Volvo V60 and the 2015-2018 Volvo V60 Cross Country are among the vehicles it fits, along with others. If your Volvo or other model is not named here, run its year, make and model through the Buyer's Guide tab. This listing is one rotor; the other side of the same axle is normally done at the same time.

Specifications

Fit and size

  • Position: Front
  • Quantity per vehicle: 2
  • Outer diameter: 316 mm (12.44 in)
  • Inner diameter: 144 mm (5.67 in)
  • Centering diameter: 63.5 mm
  • Wheel bolt bore diameter: 15.7 mm
  • Bolt circle: 108 mm (4.25 in), 6 bolt holes
  • Thickness: 28 mm (1.10 in)
  • Minimum thickness: 26 mm (1.02 in)
  • Overall height: 52 mm (2.05 in)

Build and materials

  • Type: vented, full cast, smooth surface, non-directional
  • Material: gray cast iron
  • Finish: coated disc and coated hat, rust-resistant coating
  • Balancing: mill balancing
  • ABS tone ring: not included
  • Condition: New
  • Country of origin: China

In the box

One brake rotor with fixing screws; these vehicles take two. The wheel hub, wheel studs and bearings are not included.

Installation notes

  • The surface is non-oiled, so no degreasing is needed.
  • Assembly and disassembly should be done by qualified personnel.

Frequently Asked Questions

Are these 2011-2018 Volvo S60 brake rotors front ones?

Yes. HELLA BRAKES 355118892 is a front rotor, and it fits the 2011-2018 Volvo S60.

Does this rotor fit the 2015-2018 Volvo V60 Cross Country?

Yes. HELLA BRAKES 355118892 fits the 2015-2018 Volvo V60 Cross Country and the 2015-2018 Volvo V60 on the front axle.

Are fixing screws included with this front brake rotor?

Yes, this rotor comes with fixing screws; the wheel hub, wheel studs and bearings are not included.

What size is the HELLA BRAKES 355118892 rotor?

It measures 316 mm across and 28 mm thick, with a 108 mm bolt circle and 6 bolt holes. The rotor is vented and full cast.

At what thickness is this vented rotor worn out?

This rotor is 28 mm thick new, and its minimum thickness is 26 mm. A rotor measured at or below 26 mm should be replaced.
