Rear Brake Rotor for 2009-2011 Mercedes-Benz SLK300 & More - HELLA 355104322

Be the first to review this product

$52.99

MPN: 355104322

Item Package Quantity: 1

Current Stock:

Quantity:

Adding to cart… The item has been added

Have questions?

Ask an Expert

DISC BRAKE ROTOR

$52.99

Description

The HELLA BRAKES 355104322 rear brake rotor for the 2009-2011 Mercedes-Benz SLK300 and other vehicles is a solid, full-cast disc that the rear pads clamp against to slow the wheel.

Part of the HELLA Pagid brake disc range, made from high-grade gray cast iron to OEM standards.
High carbon content improves heat dissipation for better braking performance.
A full zinc coating on the disc and hat protects against rust.
High carbon content and 'soft' casting materials absorb sound to cut noise and vibration and help prevent deformation.

Pulsing in the brake pedal, a grinding noise or deep grooves on the braking face can mean this rotor is worn, though worn pads or a sticking caliper can bring on the same complaints, so find the cause before you replace it. Rear rotors are best replaced as a pair so both sides brake alike, and this listing is one rotor.

The vehicles it fits include the 2005-2011 Mercedes-Benz SLK350 and the 2006-2009 Mercedes-Benz CLK350, and it is a direct-fit replacement for each of them. If your Mercedes-Benz isn't named here, the Buyer's Guide tab shows whether it is covered.

Specifications

Fit and size

Position: Rear
Quantity per vehicle: 2
Outside diameter: 290 mm (11.42 in)
Inner diameter: 164 mm (6.46 in)
Centering diameter: 67 mm (2.64 in)
Bolt circle: 112 mm (4.41 in), 5 lug holes
Wheel bolt bore: 13.4 mm
Nominal thickness: 10 mm (0.39 in)
Minimum thickness: 8.3 mm
Overall height: 55.4 mm

Build and materials

Type: Solid, full cast
Surface: Smooth, non-directional
Material: Gray cast iron, high-carbon
Finish: Coated disc and hat, rust-resistant
Balancing: Mill balanced
ABS tone ring: not included
Grade: Standard replacement
Country of origin: China

In the box

This listing holds one rear brake rotor and one fixing screw; the vehicles it fits take two. Wheel studs, the wheel hub and bearings are not included, and old wheel studs may not be fit to reuse, so plan on new ones if yours are worn or damaged.

Installation notes

The surface is not oiled, so no degreasing is needed before installation.
Assembly and disassembly by qualified personnel is required.

Manufacturer's Description

Product Specs

Buyer's Guide

Interchange Part Numbers

Frequently Asked Questions

Does the HELLA BRAKES 355104322 fit the rear of a 2005-2011 Mercedes-Benz SLK350?

Yes. The HELLA BRAKES 355104322 is a rear brake rotor for the 2005-2011 Mercedes-Benz SLK350, and it also fits the 2009-2011 Mercedes-Benz SLK300 and the 2006-2009 Mercedes-Benz CLK350.

What size is the HELLA BRAKES 355104322 rotor across?

The HELLA BRAKES 355104322 measures 290 mm (11.42 in) across, with a 112 mm bolt circle, 5 lug holes and a 67 mm centering diameter.

What is the minimum thickness on this rear brake rotor?

This rear brake rotor is 10 mm thick new and should be replaced once it wears down to its 8.3 mm minimum thickness.

How can I tell if my disc brake rotor is worn out?

Pedal pulsation, a grinding noise or deep grooves on the braking face can mean this rear rotor is worn, and a shop can measure it against its minimum thickness during a brake service.

Does this rear rotor come with an ABS tone ring or wheel hub?

No. This rear rotor comes with one fixing screw; the ABS tone ring, wheel hub, wheel studs and bearings are not included.
