Delphi FG0230 fuel pump module for the 1996-1997 Dodge Intrepid V6 3.3L or 3.5L and other vehicles moves fuel from the tank to the engine. This Delphi fuel pump module assembly is built to OE standards and includes the float arm that reports the fuel level to the gas gauge.
- Empty float height and float retention held to specification for a correct gas gauge reading
- Lower amperage draw puts less load on the vehicle's electrical system
- Validated, tested and matched to the right vehicle application
- Design and durability aimed at lower failure rates
Quick facts
- Part: Delphi FG0230 fuel pump module
- Also called: fuel pump assembly
- Fits: 1996-1997 Dodge Intrepid V6 3.3L or 3.5L and other vehicles
- Condition: New
A failing fuel pump module can show up as hard starting, stalling or a gas gauge that reads wrong. A clogged fuel filter, a bad fuel pump relay or a weak battery can be behind those signs too, so find the cause before you buy.
Fits
The 1996-1997 Dodge Intrepid V6 3.3L or 3.5L, the 1996 Chrysler Concorde V6 3.3L and the 1996-1997 Concorde V6 3.5L, and the 1996-1997 Chrysler Intrepid V6 3.3L or 3.5L each take one fuel pump module, and it fits more vehicles as well. Open the "Vehicles it fits" section to check your exact model and engine.
Specifications
- Quantity per vehicle: 1
- Condition: New
In the box
One fuel pump module with float arm, one seal and one instruction sheet.
Installation notes
- Check and clean the fuel tank before installing the module.
- The instruction sheet in the box covers the steps.
Interchange: 4856 445 · 4882 079 · 4897 428AB · 953-3014
MU2043 · MU249 · 4010081 · E7101M · DFG0230 · 67648 · P74707M · 4886343AA · 4897428AA · AFS0496S · RE0496S · 89032313 · C0430M · A27016 · SP7101M · USEP7101M
This part cross-references / interchanges with the following part numbers:
MU2043, MU249, 4010081, E7101M, DFG0230, 67648, P74707M, 4856 445, 4882 079, 4886343AA, 4897428AA, 4897 428AB, 953-3014, AFS0496S, RE0496S, 89032313, C0430M, A27016, SP7101M, USEP7101M
Frequently Asked Questions
Will the Delphi fuel pump module fit a 1996-1997 Dodge Intrepid V6 3.3L or 3.5L?
Yes. Delphi FG0230 fits the 1996-1997 Dodge Intrepid with either the V6 3.3L or the V6 3.5L engine, and each of those cars takes one.
What comes with the Delphi fuel module?
The Delphi FG0230 package has the fuel pump module with its float arm, a seal and an instruction sheet.
Does this Delphi module match the original float height?
Yes. The empty float height and float retention on this fuel pump module match OE specifications, so the gas gauge gives a correct reading.
Is this fuel pump assembly right for the 1996 Chrysler Concorde V6 3.3L?
Yes. Delphi FG0230 fits the 1996 Chrysler Concorde V6 3.3L and the 1996-1997 Concorde V6 3.5L.
Does Delphi FG0230 replace number 4897428AA?
Yes, 4897428AA is one of the numbers Delphi FG0230 replaces, and the rest are on the Interchange line.
