Bring your front braking back to specification with the Raybestos Brakes R-Line Disc Brake Rotor 980338R, a direct-fit front rotor for the 2004-2010 Chevrolet Optra, 2004-2008 Suzuki Forenza, 2005-2008 Suzuki Reno, and 2009 Chevrolet Epica (All engines). Raybestos R-Line rotors are engineered for everyday driving with broad coverage and dependable, consistent stops.
This vented, non-directional rotor measures 255.8 mm (10.07 in) outside diameter with a 60.2 mm (2.37 in) center hole and 4 stud/lug holes on a 114.3 mm (4.5 in) bolt circle. Nominal thickness is 24 mm (0.945 in) with a 22 mm (0.866 in) discard thickness. It is a conventional (not drum-in-hat) cast-iron rotor; the ABS tone ring is not included. Country of origin: China. Sold individually; the listed applications use two per front axle, so order two and replace both sides together as a matched set for even, balanced braking. Manufacturer part number 980338R.
Which vehicles does this front rotor fit?
It's a direct-fit front rotor for the 2004-2010 Chevrolet Optra, 2004-2008 Suzuki Forenza, 2005-2008 Suzuki Reno, and 2009 Chevrolet Epica (All engines). Check the Buyer's Guide tab to confirm your vehicle.
How many should I order?
It's sold individually. The listed applications use two per front axle, so order two and replace both sides together as a matched set for even, balanced braking.
Is this rotor vented or solid?
It is a vented, non-directional, conventional (not drum-in-hat) rotor cast from cast iron with G3000-qualified material.
Does it include an ABS tone ring?
No. The ABS tone ring is not included with this rotor per the catalog.
What are the thickness specs?
Nominal thickness is 24 mm (0.945 in) and the discard (minimum) thickness is 22 mm (0.866 in). Outside diameter is 255.8 mm (10.07 in).
