Engine Piston for 2003-2004 Dodge Ram 2500 & More - Sealed Power 2776PNA

$185.99

Sealed Power Engine Piston 2776PNA

Sealed Power Engine Piston 2776PNA - view 2

Sealed Power Engine Piston 2776PNA

Sealed Power Engine Piston 2776PNA - view 2

Part number: 2776PNA

UPC: 614046954205

Condition: New

Weight: 4.40 LBS

Item Package Quantity: 1

$185.99

Current Stock: 15

Quantity:

Adding to cart… The item has been added

Have questions?

Sealed Power Engine Piston P/N:2776PNA

Sealed Power Engine Piston P/N:2776PNA

$185.99

$185.99

Description

Sealed Power 2776PNA engine piston for the 2003-2004 Dodge Ram 2500 6-cylinder 5.9L and other vehicles turns combustion pressure into force on the connecting rod. This is one of the Sealed Power cast pistons, made for use with the E-984KC ring set.

Cast aluminum piston body
Bowl-type piston head
Compression height of 71.60 mm
Piston pin outside diameter of 40.00 mm

Quick facts

Part: Sealed Power 2776PNA engine piston
Fits: 2003-2004 Dodge Ram 2500 6-cylinder 5.9L and other vehicles
Material: Cast aluminum
Condition: New

Oil burning, blow-by, lost compression or a knock from the engine can mean a piston is worn or damaged. Worn rings or a scored cylinder wall can be behind the same signs, so find the cause before you replace the piston.

Fits

This piston fits the 2003-2004 Dodge Ram 2500 6-cylinder 5.9L and the 2003-2004 Dodge Ram 3500 6-cylinder 5.9L. The 2003-2004 Dodge Ram 3500 6-cylinder 5.9L takes six, and this listing is one piston.

Specifications

Fit and size

Quantity per vehicle: 6
Cylinder bore diameter: 102.0 mm (4.0157 in)
Compression height: 71.60 mm
Piston pin outside diameter: 40.00 mm
Top compression ring thickness: 3.00 mm
Second compression ring thickness: 2.40 mm
Oil ring thickness: 4.00 mm
Oversized: No

Build and materials

Type: cast piston
Material: Cast aluminum
Piston head: bowl
Grade: Premium
Condition: New
Country of origin: United States

In the box

One engine piston. Assembly lubricant is not included.

Manufacturer's description

Product specs

Vehicles it fits

Interchange numbers

Buyer's Q&A

Frequently Asked Questions

Does the Sealed Power 2776PNA fit the 2003-2004 Dodge Ram 3500 6-cylinder 5.9L?

Yes. Sealed Power 2776PNA fits the 2003-2004 Dodge Ram 3500 6-cylinder 5.9L, which takes six pistons.

Are Sealed Power pistons like this one cast or forged?

This Sealed Power 2776PNA is a cast piston made of cast aluminum, with a bowl-type head.

Which rings go with this Sealed Power engine piston?

The E-984KC ring set is the one to use with it. This listing is one piston, and assembly lubricant is not included.

What cylinder bore and pin size does the 2776PNA piston use?

The 2776PNA is made for a 102.0 mm (4.0157 in) cylinder bore and a 40.00 mm piston pin outside diameter. It is not oversized.

What ring thicknesses does this piston take?

The top compression ring is 3.00 mm, the second compression ring is 2.40 mm and the oil ring is 4.00 mm.
