Engine Piston for 1998-2001 Ford Ranger - Sealed H865CP .50MM

$174.99
Sealed Power Engine Piston Set H865CP.50MM
Sealed Power Engine Piston Set H865CP.50MM
MPN: H865CP.50MM
UPC: 614046657915
Item Package Quantity: 4
$174.99
Adding to cart… The item has been added

Have questions?

Ask an Expert
Sealed Power Engine Piston Set P/N:H865CP .50MM (Pack of 4)
Sealed Power Engine Piston Set P/N:H865CP .50MM (Pack of 4)
$174.99
$174.99

Sealed H865CP .50MM engine piston for the 1998-2001 Ford Ranger 4-cylinder 2.5L carries combustion pressure down to the connecting rod and seals the cylinder. It is a 0.50 mm oversize piston, used when an engine is rebuilt with the bores machined to that size.

  • Helps improve cylinder sealing for less blow-by
  • Retains standard ring gaps in the top groove
  • DUROSHIELD skirt-coated piston
  • Moly-graphite coating extends engine life and reduces friction for higher fuel economy
  • Prevents damage from inadequate lubrication on start-up

Quick facts

  • Part: Sealed H865CP .50MM engine piston
  • Fits: 1998-2001 Ford Ranger 4-cylinder 2.5L
  • Material: Hypereutectic
  • Condition: New

A worn piston or ring set can show up as oil burning, blue exhaust smoke, an engine knock or low compression. Those signs alone do not prove the piston is the problem, since a leaking valve can produce low compression too. The 2.5L four-cylinder takes four pistons, one per cylinder.

Fits

This piston fits the 1998-2001 Ford Ranger 4-cylinder 2.5L.

Specifications

Fit and size

  • Quantity per vehicle: 4
  • Oversize: 0.50 mm
  • Bore diameter: 3.7795 in
  • Piston pin outside diameter: 0.9126 in (23.18 mm)
  • Compression height: 1.200 in
  • Pin offset: 0.06 in (1.524 mm)
  • Compression ring thickness: 1.50 mm (top), 1.50 mm (second)
  • Oil ring thickness: 3.00 mm

Build and materials

  • Piston material: Hypereutectic
  • Piston head type: Recessed
  • Skirt coating: DUROSHIELD moly-graphite
  • Condition: New
  • Country of origin: India

In the box

Assembly lubricant is not included.

Installation notes

  • Minimum piston-to-bore clearance is given in the piston fitting information on the carton label.

Interchange: P453A.20 · P5001(4).50 · 3168HC.25MM

This part cross-references / interchanges with the following part numbers:

P453A.20, P5001(4).50, 3168HC.25MM

Frequently Asked Questions

Does the Sealed H865CP .50MM piston fit the 1998-2001 Ford Ranger 4-cylinder 2.5L?

Yes. Sealed H865CP .50MM is listed for the 1998-2001 Ford Ranger 4-cylinder 2.5L, which takes four pistons, one per cylinder.

What oversize and bore diameter does this Sealed piston have?

Sealed H865CP .50MM is 0.50 mm oversize with a bore diameter of 3.7795 in. Its piston pin outside diameter is 0.9126 in (23.18 mm).

Is this piston hypereutectic, and does it have a skirt coating?

Yes. The piston material is hypereutectic, and the skirt carries a DUROSHIELD moly-graphite coating that reduces friction.

Does this piston set include assembly lubricant?

No. Assembly lubricant is not included with the pistons, so it is purchased separately.

Where do I find the piston-to-bore clearance for these pistons?

The minimum clearance is given in the piston fitting information on the carton label.
