Radiator for 1998-2002 Mercedes-Benz E320 - Spectra Premium CU2290

$342.99

WARNING:California Proposition 65▾

Part number: CU2290

UPC: 671607729504

Condition: New

Weight: 19.27 LBS

Item Package Quantity: 1

$342.99

Current Stock: 9

Quantity:

Adding to cart… The item has been added

Have questions?

Ask an Expert

Spectra Premium Radiator P/N:CU2290

$342.99

Description

Spectra Premium CU2290 radiator for the 1998-2002 Mercedes-Benz E320 V6 3.2L cools the engine coolant as it flows through the core. Its structure and design are built for the same durability and expectations as the OE.

Aluminum core with plastic tanks and a single core row
Cross-flow layout with the inlet at the top left and the outlet at the bottom right
Internal concentric transmission oil cooler included
Bottom post and top saddle mounting

Quick facts

Part: Spectra Premium CU2290 radiator
Fits: 1998-2002 Mercedes-Benz E320 V6 3.2L
Material: Aluminum core, plastic tanks
Condition: New

Coolant seeping from a tank or core seam, cracks in the plastic tanks, or a temperature gauge that climbs can point to a failing radiator. A thermostat, water pump, radiator cap or coolant hose can be behind those signs too, so find the cause before buying a replacement.

Fits

It fits the 1998-2002 Mercedes-Benz E320 V6 3.2L, and the engine takes a single radiator.

Specifications

Fit and size

Quantity per vehicle: 1
Core height: 25.25 in
Core width: 19.25 in
Core thickness: 1.25 in
Core rows: 1
Inlet and outlet diameter: 1.5 in each
Inlet and outlet headers: 20.125 in long, 2.5 in wide each
Transmission oil cooler distance between fittings: 12.375 in

Build and materials

Type: Cross flow
Core material: Aluminum
Tank material: Plastic
Transmission oil cooler: Internal, concentric
Mounting: Bottom post / top saddle
Condition: New
Country of origin: China

In the box

One radiator with its internal transmission oil cooler. A frame and an engine oil cooler are not included.

Manufacturer's description

Product specs

Vehicles it fits

Interchange numbers

Buyer's Q&A

Frequently Asked Questions

Is this radiator the right one for the 1998-2002 Mercedes-Benz E320 V6 3.2L?

Yes. Spectra Premium CU2290 is listed for the 1998-2002 Mercedes-Benz E320 V6 3.2L, which takes one radiator.

Does the Spectra Premium CU2290 come with a transmission oil cooler?

Yes. It has an internal concentric transmission oil cooler, with 12.375 in between the fittings. A frame and an engine oil cooler are not included.

Is this cross-flow radiator made of aluminum or plastic?

The core is aluminum and the tanks are plastic. It has a single core row.

What signs of a leaking radiator can I look for?

With the engine off and cool, look for coolant stains or wetness around the tanks and core seams, or cracks in the plastic tanks. A temperature gauge that climbs in normal driving can also be a sign.

What size are the inlet and outlet on this radiator?

Both the inlet and the outlet are 1.5 in in diameter. The core measures 25.25 in high by 19.25 in wide.
