Spectra Premium CU2711 radiator for the 2003-2009 Dodge Ram 2500 6-cylinder 5.9L, the 2007-2009 Ram 2500 6-cylinder 6.7L and other vehicles moves engine coolant through an aluminum core to carry heat away from the engine. This Spectra Premium radiator is built to the same durability expectations as the OE.
- Aluminum core with plastic tanks
- Cross-flow design with a single core row
- 2 in inlet and 2 in outlet connections
- Bottom post and top flange mounting
Quick facts
- Part: Spectra Premium CU2711 radiator
- Fits: the 2003-2009 Dodge Ram 2500 6-cylinder 5.9L, the 2007-2009 Ram 2500 6-cylinder 6.7L and other vehicles
- Material: Aluminum core, plastic tanks
- Condition: New
Coolant leaking at the core or tanks, a coolant level that keeps dropping, or an engine that runs hot can mean the radiator is failing. Before you replace it, rule out a loose hose clamp, a worn radiator cap, a stuck thermostat and a weak water pump, since each can also leave the engine hot or the coolant low.
Fits
The 2003-2009 Dodge Ram 2500 6-cylinder 5.9L, the 2007-2009 Ram 2500 6-cylinder 6.7L, the 2003-2007 Ram 3500 6-cylinder 5.9L and the 2007-2009 Ram 3500 6-cylinder 6.7L all take this radiator, and so do the 2005-2009 Dodge Ram 4000 6-cylinder 5.9L and many other vehicles. If your truck is not one of these, look up its year and engine in the "Vehicles it fits" section.
Specifications
Fit and size
- Quantity per vehicle: 1
- Core: 29.4375 in wide, 27 in high, 1.25 in thick
- Inlet and outlet diameter: 2 in each
- Inlet and outlet headers: 30.3125 in long, 2.75 in wide
- Inlet location: top left
- Outlet location: bottom right
- Mounting type: Bottom Post / Top Flange
Build and materials
- Type: cross flow, 1 core row
- Core material: aluminum
- Tank material: plastic
- Frame: not included
- Condition: New
- Country of origin: China
In the box
One radiator, and the application takes one. A frame, engine oil cooler and transmission oil cooler are not included.
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Is the Spectra Premium CU2711 a Ram 2500 radiator for the 2007-2009 Ram 2500 6-cylinder 6.7L?
Yes. Spectra Premium CU2711 fits the 2007-2009 Ram 2500 6-cylinder 6.7L and the 2003-2009 Dodge Ram 2500 6-cylinder 5.9L, one radiator per truck.
Is this a Ram 3500 radiator for the 2003-2007 Ram 3500 6-cylinder 5.9L?
Yes. It also fits the 2007-2009 Ram 3500 6-cylinder 6.7L. For another year or engine, look up your vehicle in the "Vehicles it fits" section.
What size are the inlet and outlet on this cross-flow radiator?
The Spectra Premium CU2711 has a 2 in inlet at the top left and a 2 in outlet at the bottom right. Both headers are 30.3125 in long and 2.75 in wide.
Is this radiator aluminum or plastic?
Both. The core is aluminum and the tanks are plastic. The core is 29.4375 in wide, 27 in high and 1.25 in thick, with one core row.
Does this radiator include a transmission oil cooler?
No. This radiator has no internal engine or transmission oil cooler, and no frame comes with it.
