Spectra Premium CU292 radiator for the 1990-1993 Acura Integra 4-cylinder 1.8L and the 1992-1993 Integra 4-cylinder 1.7L cools the engine by releasing heat from the coolant. The Spectra Premium radiator is built to the same durability and expectations as the OE.
- Single-row aluminum core with plastic tanks, 26.3125 in wide and 12.875 in high
- Built-in concentric transmission oil cooler with M14x1 male fittings
- Down-flow layout with the inlet at the top left and the outlet at the bottom right
- Post-type mounting with 1.25 in inlet and outlet diameters
Quick facts
- Part: Spectra Premium CU292 radiator
- Fits: the 1990-1993 Acura Integra 4-cylinder 1.8L and the 1992-1993 Integra 4-cylinder 1.7L
- Material: Aluminum core, plastic tanks
- Condition: New
Coolant leaks, a coolant smell or an engine that runs hot can mean a radiator problem, but hoses and other cooling parts leak too. With the engine off and cool, look over the tanks and core for stains, cracks or seepage first.
Fits
This radiator is a direct-fit replacement for the 1990-1993 Acura Integra 4-cylinder 1.8L and the 1992-1993 Integra 4-cylinder 1.7L.
Specifications
Fit and size
- Quantity per vehicle: 1
- Core: 26.3125 in wide, 12.875 in high, 1 in thick, 1 row
- Inlet and outlet diameter: 1.25 in each
- Inlet and outlet header: 27.125 in long, 2 in wide each
- Inlet location: top left
- Outlet location: bottom right
- Flow type: down flow
- Mounting type: post
- Oil cooler fittings: M14x1 male, 12.75 in apart
Build and materials
- Core material: aluminum
- Tank material: plastic
- Transmission oil cooler: concentric, internal
- Condition: new
- Country of origin: China
In the box
One radiator with a built-in transmission oil cooler. A frame and an engine oil cooler are not included. This listing is one radiator, and the quantity per vehicle is one.
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Is this Integra radiator right for the 1992-1993 Acura Integra 4-cylinder 1.7L?
Yes. Spectra Premium CU292 is listed for the 1992-1993 Acura Integra 4-cylinder 1.7L and for the 1990-1993 Integra 4-cylinder 1.8L.
Does the Spectra Premium CU292 radiator come with a transmission oil cooler?
Yes. Spectra Premium CU292 has a built-in concentric transmission oil cooler with M14x1 male fittings. A frame and an engine oil cooler are not included.
What is the CU292 radiator made of?
The core is aluminum and the tanks are plastic. It is a single-row core, 26.3125 in wide, 12.875 in high and 1 in thick.
What signs can show an aluminum-core radiator with plastic tanks is failing?
Coolant stains, visible seepage at the tanks or an engine temperature that climbs can be signs. A shop can pressure-test the cooling system to find the source.
What size are the inlet and outlet connections on the CU292 radiator?
Both measure 1.25 in in diameter. The inlet is at the top left and the outlet is at the bottom right of this down-flow radiator.
