Standard Ignition LX-786 ignition control module for the 1985-1988 Toyota Pickup 4-cylinder 2.4L triggers the ignition coils from the crankshaft position sensor signal. Its design targets the inherent failure issues that can affect the original equipment module.
- Copper slug heat sinks that dissipate heat to protect the module
- High-temperature polymer housing that reduces moisture intrusion and minimizes vibration damage
- Double wire bonds that hold up under intense vibration and a tough operating environment
- Durability tested for 500 thermal cycles from -40C to +125C
- Module responds to a weak crankshaft position sensor signal and begins energizing the coils immediately for cold-weather starts
Quick facts
- Part: Standard Ignition LX-786 ignition control module
- Fits: 1985-1988 Toyota Pickup 4-cylinder 2.4L
- Condition: New
Hard starting, stalling or a misfire can mean the module is failing. Before you replace it, rule out the crankshaft position sensor, the ignition coil and the wiring, because a fault in any of them can look like a bad module.
Fits
This module is a direct-fit replacement for the 1985-1988 Toyota Pickup 4-cylinder 2.4L, which takes one.
Specifications
Fit and size
- Quantity per vehicle: 1
- Voltage: 12 V
- Connectors: 4, round and rectangular
- Terminals: 9, blade type
Build and materials
- Ignition type: distributorless
- Attachment method: bolt on
- Terminal gender: male; connector gender: male and female
- Condition: new
- Country of origin: China
In the box
One ignition control module. Mounting hardware, a mounting bracket, instructions and the ignition coil are not included, so plan on new bolts, since the old ones may not be reusable.
Frequently Asked Questions
Is the Standard Ignition LX-786 the right ignition control module for the 1985-1988 Toyota Pickup 4-cylinder 2.4L?
Yes. Standard Ignition LX-786 is a direct-fit ignition control module for the 1985-1988 Toyota Pickup 4-cylinder 2.4L, and that engine takes one.
Does the LX-786 ignition control module come with mounting bolts or a bracket?
No. Standard Ignition LX-786 is one module only; mounting hardware, a mounting bracket, instructions and the ignition coil are not included.
How many connectors and terminals does this ignition control module have?
This module has four connectors, round and rectangular, and nine male blade terminals. It is a 12-volt part.
Could a failing ignition control module be why my engine cranks but won't start?
It can be, since hard starting, stalling and misfires can come from a failing module. A sensor, coil or wiring fault can look the same, so a shop can test it.
How is the Standard Ignition LX-786 tested for heat and cold?
Standard Ignition LX-786 is durability tested for 500 thermal cycles from -40C to +125C. Its copper slug heat sinks help draw heat away from the module.
