Timken HA500601 front wheel bearing and hub assembly for the 2010-2016 Land Rover LR4 and other vehicles carries the wheel and lets it spin. OE-developed tests control the design, materials and process used to make it.
- Preset, pre-greased and pre-sealed hub unit bearing assembly
- Low runout reduces noise and vibration and improves braking performance
- Seals with a reinforced outer case, ribbed rubber inner diameter, contamination exclusion system and vent holes to prevent installation damage
- Bearings with precision profiles, uniform internal geometry and enhanced surface finishes to increase load carrying capacity and extend bearing life
Quick facts
- Part: Timken HA500601 wheel bearing and hub assembly
- Fits: 2010-2016 Land Rover LR4 and other vehicles
- Position: Front
- Condition: New
A humming or growling noise that changes with speed, vibration, or play in the wheel can mean the bearing is wearing out. Before you replace the wheel bearing and hub assembly, rule out unbalanced or unevenly worn tires and brake parts, which can cause similar noise and vibration. Front assemblies are normally replaced as a pair, and this listing is one.
Fits
This Timken wheel bearing and hub assembly is a direct-fit replacement for the 2010-2016 Land Rover LR4, the 2006-2013 Land Rover Range Rover Sport and the 2005-2009 Land Rover LR3.
Specifications
Fit and size
- Position: Front
- Quantity per vehicle: 2
- Bolt circle diameter: 120.00 mm (4.724 in)
- Flange bolt holes: 4
- Wheel studs: 5
- Flange diameter: 158.50 mm (6.240 in)
- Flange offset: 58.50 mm (2.303 in)
- Brake pilot diameter: 78.97 mm (3.109 in)
- Hub pilot diameter: 89.04 mm (3.506 in)
- Wheel pilot diameter: 72.53 mm (2.856 in)
- Spline quantity: 29
Build and materials
- Drive type: Driven
- ABS sensor: 100% tested to monitor wheel speed for the anti-lock braking system
- Condition: New
In the box
One wheel bearing and hub assembly. This listing holds one, and the front axle uses two.
Interchange: 400.22000
WE61565 · 515067 · BR930604
This part cross-references / interchanges with the following part numbers:
WE61565, 400.22000, 515067, BR930604
Frequently Asked Questions
Is this Timken wheel bearing a fit for the 2006-2013 Land Rover Range Rover Sport?
Yes. Timken HA500601 is a front wheel bearing and hub assembly that fits the 2006-2013 Land Rover Range Rover Sport, which uses two of them.
Is this one of the Timken wheel hubs that comes pre-greased and pre-sealed?
Yes. This Timken HA500601 wheel bearing and hub assembly is preset, pre-greased and pre-sealed, so it is built ready to install.
What are the key sizes on Timken front wheel bearings like this HA500601?
The bolt circle diameter is 120.00 mm (4.724 in). The flange has 4 bolt holes, the assembly has 5 wheel studs, and the flange diameter is 158.50 mm (6.240 in).
How can I tell if Timken hub bearings like this are wearing out?
Common signs are a hum or growl that changes with speed, vibration, or play in the wheel. A shop can confirm it; have a suspected worn bearing checked promptly.
Does Timken HA500601 interchange with 515067?
Yes. 515067 is one of the numbers this Timken HA500601 replaces, along with 400.22000, WE61565 and BR930604.
