Delphi FG2850 fuel pump module for the 2020-2025 Toyota Corolla 4-cylinder 1.8L and other vehicles pumps fuel from the tank to the engine. Delphi is a global OE manufacturer and builds all its fuel pumps to its OE standards.
- Empty float height and float retention are set to specification for a correct gas gauge reading
- Lower amperage draw puts less load on the vehicle's electrical system
- Validated, tested and matched to the right vehicle application
- Design and durability that give lower failure rates
Quick facts
- Part: Delphi FG2850 fuel pump module
- Also called: fuel pump assembly
- Fits: the 2020-2025 Toyota Corolla 4-cylinder 1.8L and other vehicles
- Condition: New
A car that is hard to start, stalls, or shows a fuel gauge that reads wrong may have a worn fuel pump assembly, but those signs can come from other faults too. Find the cause first; a shop can test fuel pressure and delivery.
Fits
This fuel pump module also fits the 2019-2022 Toyota Prius 4-cylinder 1.8L and the 2019-2022 Toyota Prius Prime 4-cylinder 1.8L.
Specifications
Fit and size
- Quantity per vehicle: 1
- Engine: 4-cylinder 1.8L (L4-1.8L)
Build and materials
- Condition: New
- Country of origin: Thailand
In the box
One fuel pump module with float arm, seal, splices, wire harness and instruction sheet. This listing holds one module, and the car takes one.
Installation notes
- An instruction sheet comes with the module for the installation steps.
- Check and clean the fuel tank during installation.
Interchange: 23221-47031 · 77020-12A80
Frequently Asked Questions
Will the Delphi FG2850 work in a 2019-2022 Toyota Prius Prime 4-cylinder 1.8L?
Yes. The Delphi FG2850 fuel pump module fits the 2019-2022 Toyota Prius Prime with the 4-cylinder 1.8L engine, and the car takes one.
What comes with this Delphi fuel pump module assembly?
The Delphi FG2850 includes a float arm, seal, splices, wire harness and an instruction sheet. This listing is one module.
Does the Delphi fuel module keep the fuel gauge accurate?
Its empty float height and float retention match OE specifications, which is meant to give a correct gas gauge reading. A shop can confirm the cause if a gauge still reads wrong.
Does the Delphi module put less load on the electrical system?
Yes. This fuel pump module is built for lower amperage draw, so it puts less load on the vehicle's electrical system.
Does the Delphi fuel pump module replace number 23221-47031?
Yes. 23221-47031 is one of the numbers the Delphi FG2850 replaces.
