Gates TCKWP184A timing belt kit with water pump for the 1990-1995 Acura Integra 4-cylinder 1.8L replaces the timing belt, tensioner and water pump together. This Gates timing belt kit with water pump puts the parts that wear together in one box.
- PowerGrip Premium line kit that adds a water pump to the Gates timing belt components
- HSN timing belt with fiberglass cord and a modified curvilinear (III) tooth type
- Water pump designed and built for long lasting, efficient cooling
- Spring tensioner and tensioner spring supplied with the belt
Quick facts
- Part: Gates TCKWP184A timing belt kit with water pump
- Also called: engine timing belt kit with water pump
- Fits: 1990-1995 Acura Integra 4-cylinder 1.8L
- Material: HSN, fiberglass cord (belt)
- Condition: New
A belt-driven water pump should always be replaced with the timing belt, so this engine timing belt kit with water pump covers both. Coolant seepage at the pump, or a belt with cracks, fraying or missing teeth, can mean the kit is due. Before replacing it, check the pump area by eye with the engine off and cool; overheating can also come from other parts, so find the cause first.
Fits
The kit is a direct-fit replacement for the 1990-1995 Acura Integra 4-cylinder 1.8L, which takes one kit.
Specifications
Fit and size
- Quantity per vehicle: 1 kit
- Belt width: 26 mm (1.024 in)
- Belt teeth: 125
Build and materials
- Tensioner type: Spring
- Belt material: HSN, fiberglass cord
- Grade type: OE Exact
- Condition: New
- Warranty: Gates warranty matches the original manufacturer's timing belt replacement intervals for parts, labor and other associated costs
- Country of origin: China
In the box
One timing belt, one spring tensioner, one tensioner spring, one water pump and one rubber seal ring. An idler pulley, bolts and an installation tool are not included, so plan on new bolts.
Installation notes
- Detailed installation instructions come with the kit, sheet number 0098-1618.
Interchange: TKH-013 · WPK-0042
AWK1301 · PP184LK4 · TB184LK4 · TB184LK2 · WP184K1A · WP184K1AS · GTKWP184B · 20332K · BWPK41041 · WPK41041 · USTK184A
This part cross-references / interchanges with the following part numbers:
TCKWP184A, TKH-013, WPK-0042, AWK1301, PP184LK4, TB184LK4, TB184LK2, WP184K1A, WP184K1AS, GTKWP184B, 20332K, BWPK41041, WPK41041, USTK184A
Frequently Asked Questions
Is the Gates TCKWP184A timing belt kit right for the 1990-1995 Acura Integra 4-cylinder 1.8L?
Yes. Gates TCKWP184A fits the 1990-1995 Acura Integra 4-cylinder 1.8L, and that engine takes one kit.
Does the Gates TCKWP184A kit come with an idler pulley or bolts?
No. This Gates TCKWP184A kit holds a timing belt, a spring tensioner, a tensioner spring, a water pump and a rubber seal ring. The idler pulley, bolts and installation tool are not included.
How wide is the timing belt in this kit and how many teeth does it have?
The belt is 26 mm (1.024 in) wide and has 125 teeth, with a modified curvilinear (III) tooth type.
What does the Gates warranty cover on this timing belt kit?
Gates warranty matches the original manufacturer's timing belt replacement intervals. It covers parts, labor and other associated costs.
Do the instructions come with this timing belt kit?
Yes. Detailed installation instructions come in the box under sheet number 0098-1618.
