The Raybestos Brakes FRC10946 front left brake caliper for the 1998-2005 Chevrolet Blazer and other vehicles is remanufactured, and it turns hydraulic pressure from the brake pedal into clamping force at that wheel.
- Raybestos R-Line semi-loaded disc brake caliper, a remanufactured OE part.
- Castings, guide pins and brackets are inspected before they are reused.
- Materials match OE specifications and the vehicle-specific design.
- Seals, boots, bleeder screws, abutment hardware, banjo bolts and O-rings are replaced with new parts for leak-free operation.
- Every caliper is 100% pressure tested.
- EPDM70 rubber components for heat resistance, performance and durability.
A sticking or leaking brake caliper can show up as the vehicle pulling to one side when you brake, a wheel that drags, or brake fluid wetness around the caliper. Before you replace it, rule out a restricted brake hose, worn suspension parts and uneven tire pressure, because any of them can also pull a vehicle sideways under braking.
This caliper is a direct-fit front left replacement for the 1998-2005 GMC Jimmy and the 1998-2004 Chevrolet S10 as well, and each of them takes one. This listing is the left side only, and the right caliper on the front axle is normally replaced at the same time. You'll find the other vehicles it fits in the "Vehicles it fits" section.
Specifications
Fit and size
- Position: front left
- Quantity per vehicle: 1
- Pistons: 2
- Piston diameter: 1.810 in (45.974 mm)
- Bleeder screw thread: M10x1.50
- Bracket mounting hole: M14, 2 mm thread pitch
- Casting number: 355
Build and materials
- Condition: remanufactured
- Caliper type: floating
- Casting material: cast iron
- Finish: coated caliper and bracket
- Country of origin: Mexico
In the box: the caliper and its mounting bracket as one assembly.
Interchange: 99-17302B · 16-4695 · 18-4695XB · 18-B4695 · 18-P4695 · 141.66026 · 142.66026 · 14-4246
SC0189
This part cross-references / interchanges with the following part numbers:
99-17302B, 16-4695, 18-4695XB, 18-B4695, 18-P4695, 141.66026, 142.66026, SC0189, 14-4246
Frequently Asked Questions
Is this the front left 1998-2004 Chevy S10 brake caliper?
Yes. The Raybestos Brakes FRC10946 is a front left brake caliper for the 1998-2004 Chevrolet S10, which takes one on that corner.
Will this brake caliper fit the front left of a 1998-2005 Chevrolet Blazer or 1998-2005 GMC Jimmy?
Yes. The Raybestos Brakes FRC10946 fits the front left position on both, and the other vehicles it fits are listed in the "Vehicles it fits" section.
Does the FRC10946 caliper come with its mounting bracket?
Yes. This remanufactured caliper ships as a caliper and bracket assembly, so the mounting bracket is included.
What piston size and bleeder thread does this floating caliper have?
This floating caliper has two pistons with a 1.810 in (45.974 mm) piston diameter, and its bleeder screw thread is M10x1.50.
What gets replaced with new parts when this R-Line caliper is remanufactured?
This R-Line caliper gets new seals, boots, bleeder screws, abutment hardware, banjo bolts and O-rings, while its castings, guide pins and brackets are inspected before reuse.
